SIRUI Exact 3-axis gimbal with focus motor for cameras

Technical data – external device

Accessory connection

• Mechanical: 1/4″, 3/8″ threaded connection
• USB-A power connector: 5V / 1A
• Camera control port: 5V / 1A
• Camera HDMI port: Standard HDMI port
• TYP-C port: 5V/1A (without follow focus) 5V/1A 12V-16.8V (with follow focus) DC08: 8V/2A DC5.5: 16.8V/2

Input power (battery data)

• Model: SK01-2500mAh-14.4V
• Type: 18650 LiPo
• External device capacity: 2500 mAh
• Battery Cells: 4 (4S1P)
• Energy: 36 Wh
• Usage time: 10h
• Charging time: 25W quick charge 1.5h / 18W quick charge 2.5h / 5V/2A 4h

Connections

• Bluetooth® 4.2
• WIFI: 2.4G and 5G Dual Channel
• USB-A: USB communication

Requirements SIRUI Master App

• IOS 9.0 or above
• Android 5.0 or above

Technical Data – Performance

Max. Payload: 5 kg
Max. Rotation speed: 120°/s

Mechanical end point range

• Pivot axis: oo infinity
• Tilt axis: +205° to -115°
• Roll axis: +230° to -90°

Controlled rotation range

• Pan axis: 360° continuous rotation (360° mode)
• Tilt axis: +180° to -90° (upright mode) +90° to -135° (underbed mode, flashlight mode)
• Roll axis: ±30° (normal mode) 360° continuous rotation

Technical data – Mechanical and electrical characteristics

Working current: Static current: 220 ± 20 mA (not connected to camera) 300 ± 20 mA (connected to camera)

WIFI operating frequency range: 2.4 GHz to 2.48 GHz / 5 GHz to 5.8 GHz

WIFI Transmitter Power: 15dBm

Operating Temperature: -20° to +45°

Weight: approx. 1.46 kg (gimbal only) / approx. 1.84 kg (gimbal + handle)

Dimensions: approx. 202 x 185 x 486 mm
